Ultrasonic Cell Crusher|Ultrasonic Homogenizer

Ultrasonic Cell Crusher|Ultrasonic Homogenizer

1.Microcomputer control, can store 20 groups of working data. 2.Ultrasonic time and ultrasonic power can be set. 3.Automatic detection of ultrasonic power to prevent ultrasonic power from changing with the temperature of the sample.

Ultrasonic cell crusher, also known as ultrasonic crusher, ultrasonic emulsifier, is a multi-functional and multi-purpose instrument that uses ultrasonic waves to produce cavitation effects in liquids; it can be used for a variety of animals and plants, viruses, cells, bacteria and It can also be used for emulsification, separation, homogenization, extraction, defoaming, clearing, vegetation of nanomaterials, dispersion and acceleration of chemical reactions, etc.


Instruments are widely used in teaching, research and production in the fields of biology, microbiology, physics, zoology, agronomy, and pharmaceuticals.


Product introduction of ultrasonic homogenizer:


1. Drug extraction, cell, bacteria, virus tissue fragmentation. such as extraction of cellular contents.

2. Dispersion, homogenization, and emulsification of material particles. such as the dispersion of nanomaterials.

3. Accelerate the dissolution and accelerate the chemical reaction. If used for chemical synthesis, this ultrasonic equipment is equipped with a soundproof box bracket, a special soundproof box, and a low temperature system.

4. Ultrasonic crushing is an application of sonochemical equipment, which can be used for plant extraction, water treatment, solid-liquid dispersion, deagglomeration of particles in liquid, promotion of solid-liquid reaction and other effects, so that larger particle size aggregates are dispersed into smaller particles. Stabilization refers to ensuring that the powder particles remain uniformly dispersed in the liquid for a long time.


Ultrasonic Cell Crusher Main feature:


●4.7-inch large-screen LCD touch screen display.

●Microcomputer control, can store 20 groups of working data.

●Ultrasonic time and ultrasonic power can be set.

●Automatic detection of ultrasonic power to prevent ultrasonic power from changing with the temperature of the sample.

● Integrated temperature control prevents overheating of the sample.

●Automatic frequency tracking, automatic fault alarm.

●Single ultrasonic time: 0.1-99.9S

●Single interval time: 0.1-99.9S

●Total working time: 1S-99H59M59S

●Working mode: intermittent or continuous

●Frequency: 19.5-20.5KHz


Ultrasonic Cell CrusherUltrasonic HomogenizerUltrasonic Cell Crusher|Ultrasonic Homogenizer

Common problem:

1. Q: When there are multiple sets of work data, can it be selected?

A: Our products are controlled by microcomputer, which can store 20 groups of working data. No matter which set of data you use, you can switch it quickly and easily.

2. Q: When the sample temperature changes, the ultrasonic power also changes?

A: Our products can set ultrasonic time and ultrasonic power. And it will automatically detect the ultrasonic power to prevent the ultrasonic power from changing with the sample temperature.

3. Q: Does it work intermittently or can it work continuously?

A: Our model of ultrasonic cell crusher can work intermittently or continuously. It also integrates temperature control and automatic frequency tracking to prevent overheating of the sample and an automatic alarm in the event of a malfunction.

Model

Ultrasonic Frequency(KHZ)

Maximum Power (W)

Optional
probe(Φ mm)

Crusher Capacity (ml)

Sample temperature monitor

UH-150W

20-25

0-150

2,3,6

0.1-150

Yes

UH-250W

20-25

0-250

2,3,6,8

0.1-250

Yes

UH-500W

20-25

0-500

2,3,6,8,10

0.1-500

Yes

UH-650W

20-25

0-650

2,3,6,10,12,

0.1-650

Yes

UH-900W

20-25

0-900

2,3,6,8,10,12

0.1-900

Yes

UH-950W

20-25

0-9500

2,3,6,10,12,15

0.1-950

Yes

UH-1200W

19.5-20.5

0-1200

3,6,10,15,20,22

5-1200

Yes

UH-1500W

19.5-20.5

0-1500

10,15,20,22,25

20-1500

Yes

UH-1800W

19.5-20.5

0-1800

15,20,22,25

50-1800

Yes

UH-2000W

19.5-20.5

0-2000

15,20,22,25

50-2000

Yes

UH-2200W

19.5-20.5

0-2200

15,20,22,25

50-2200

Yes
